XP9090CO
900 × 900 mm
XPS Tile-Over Shower Trays
Choose an XPS shower tray by overall size and waste position. Each tray provides a ready-to-tile surface with a factory-formed fall; use the model drawing to confirm dimensions, drain position and installation detail before ordering.
System note: The XPS tray is one part of the installed shower system. Subfloor support, plumbing, waterproofing, wall junctions and the finished entry detail must follow the installation guide and project requirements.
Centre-waste trays
Five sizes with the round waste positioned centrally. Open the matching drawing for exact dimensions and recess details.
XP12090CO
1200 × 900 mm
XP120120CO
1200 × 1200 mm
XP150100CO
1500 × 1000 mm
XP200100CO
2000 × 1000 mm
Offset-waste trays
Five rectangular options with the round waste offset from centre. Drain position varies by model, so confirm it on the drawing before ordering.
XP12090
1200 × 900 mm
XP15090
1500 × 900 mm
XP90150
1500 × 900 mm
XP150100
1500 × 1000 mm
XP200100
2000 × 1000 mm
Plan the complete installation
- Select the tray size and drain layout from the model drawings.
- Confirm subfloor support, recess, plumbing position and required finished entry detail.
- Install, waterproof and tile the complete shower area in accordance with the guide and project requirements.
Installation resources
Review the procedure before ordering or installation. Customer project photos are also available as practical examples; they do not replace the installation instructions.
